2N7002LT1 ,MOSFET, MOSFET Transistor - ON Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

115 points

Part No

2N7002LT1
Manufacturer

ON Semiconductor
ChipWorker Part#

CW49999896
Category

MOSFET, MOSFET Transistor
Package

SOT-23-3
Description

Trans MOSFET N-CH 60V 0.115A 3Pin SOT-23 T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

66000 pcs In Stock
Estimated Price

$ 0.03

Buy 2N7002LT1

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

2N7002LT1 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

2N7002LT1 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	2N7002LT1
Manufacturer	ON Semiconductor
ChipWorker Part#	CW49999896
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SOT-23-3
Voltage Rating (DC)	60.0 V
Current Rating	115 mA
Drain to Source Resistance (on) (Rds)	7.50 Ω
Polarity	N-Channel
Power Dissipation	0.3 W
Drain to Source Voltage (Vds)	60 V
Breakdown Voltage (Drain to Source)	60.0 V
Breakdown Voltage (Gate to Source)	±20.0 V
Continuous Drain Current (Ids)	115 mA
Input Capacitance (Ciss)	50pF @25V(Vds)
Input Power (Max)	225 mW
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	225mW (Ta)
	expand all
Operating Temperature	-55℃ ~ 150℃ (TJ)
Product Lifecycle Status	Unknown
Packaging	Cut Tape (CT)
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

Small Signal MOSFET 60 V, 115 mA, N−Channel SOT−23 Features 60 V, 115 mA, N−Channel SOT−23 Pb−Free Packages are Available
