3003350 - Phoenix

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

3003350
Manufacturer

Phoenix
ChipWorker Part#

CW34242132
Category

Terminal Block, Connector Terminal
Description

PHOENIX CONTACT 3003350 DIN Rail Mount Terminal Block, 2Positions, 24AWG, 14AWG, 4mm², Screw, 24A
Documentation

Datasheet

3003350 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

3003350 Specifications

Attribute	Attribute Value

Part Number	3003350
Manufacturer	Phoenix
ChipWorker Part#	CW34242132
Category	Terminal Block, Connector Terminal
Documentation	Datasheet
Mounting Style	DIN Rail, Screw
Pin Pitch	5.2 mm
Number of Contacts	2 Contact
Wire Gauge	12AWG ~ 30AWG
Voltage Rating (AC)	800 V
Current Rating	24 A
Number of Rows	2 Row
Number of Circuits	1 Circuit
Flammability Rating	UL 94 V-2
Number of Positions	2 Position
Current Rating (Max)	24 A
Voltage Rating (Max)	800 V
Voltage Rating	800 V
Operating Voltage (Max)	800 V
	expand all
Size-Length	42.5 mm
Size-Width	5.2 mm
Size-Height	49.5 mm
Housing Color	Blue
Color	Blue
Housing Material	Nylon
Product Lifecycle Status	Active
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16
HTS Code	8536904000
ECCN Code	EAR99

Product Description

The 3003350 is a 2-position 1-level blue Feed-through Terminal Block with a polyamide insulator, the M3 screw connection and the NS 35/7,5, NS 35/15, NS 32 mounting. This UK 2,5 N BU universal screw terminal block series has the typical features which are decisive for practical applications. It provides potential distribution via fixed bridges in the terminal centre or insertion bridges in the clamping space. Save time and space with a multi-conductor connection. It accepts 24 to 14AWG wire range.
Universal foot which can be used on NS 35 and NS 32 DIN rails
7mm Stripping length
UL94V-2 Flammability rating
