4300.0096 - Schurter

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

4300.0096
Manufacturer

Schurter
ChipWorker Part#

CW4915130
Category

Power Entry Module
Package

Module
Description

Mains Power Connector, 2.5A, 250VAC, Male, Solder Terminal, Socket, ROHS COMPLIANT
Documentation

Datasheet

4300.0096 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

4300.0096 Specifications

Attribute	Attribute Value

Part Number	4300.0096
Manufacturer	Schurter
ChipWorker Part#	CW4915130
Category	Power Entry Module
Documentation	Datasheet
Mounting Style	Solder, Panel
Number of Pins	2 Pin
Case/Package	Module
Number of Contacts	2 Contact
Gender	Male
Voltage Rating (DC)	250 V
Voltage Rating (AC)	250 V
Current Rating	2.5 A
Flammability Rating	UL 94 V-0
Number of Positions	2 Position
Current Rating (Max)	2.5 A
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	-25 ℃
Voltage Rating (Max)	250 VAC
Voltage Rating	250 VAC
	expand all
Size-Length	35.0 mm
Size-Height	15 mm
Color	Black
Contact Material	Copper Alloy
Operating Temperature	-25℃ ~ 70℃
Housing Material	Thermoplastic
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2016/06/20
HTS Code	8536698000
ECCN Code	EAR99

Product Description

The 4300.0096 is a rear-side screw-on panel-mount IEC C8 Inlet with solder terminal. This 0720-FP series inlet is suitable for appliances with protection class II according to IEC 61140. The housing is made of black UL94V-0 thermoplastic.
Contact pins rolled
IP40 Protection rating
Solder tag contacts
Housing Material: Thermoplastic, Black, UL 94V-0
Protection Class: Class I acc. to IEC 61140
Operating Temperature: -25°C to +70°C
Cut-Out: 21x12.4mm, R6.2mm
Fixing Centres: 28mm
