65100516121 ,USB Connector - Wurth Electronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

115 points

Part No

65100516121
Manufacturer

Wurth Electronics
ChipWorker Part#

CW7765266
Category

USB Connector
Package

SMD
Description

USB Connector, Mini USB Type B, USB 2.0, Receptacle, 5Positions, Surface Mount, Right Angle
Documentation

Datasheet
Ships from

Moscow
Наличие

602 pcs In Stock
Estimated Price

$ 1.36

Buy 65100516121

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

65100516121 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

65100516121 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	65100516121
Manufacturer	Wurth Electronics
ChipWorker Part#	CW7765266
Category	USB Connector
Documentation	Datasheet
Mounting Style	Surface Mount
Case/Package	SMD
Number of Contacts	5 Contact
Gender	Female
Contact Plating	Gold
Current Rating	1 A
Insulation Resistance	1 GΩ
Orientation	Right Angle
Flammability Rating	UL 94 V-0
Number of Positions	5 Position
Contact Resistance	20.0 mΩ
Number of Mating Cycles	1500 Cycle
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Voltage Rating	30 V
	expand all
Color	Black
Contact Material	Copper Alloy
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC

Similar & Replacement Parts

Similar products

Product Description

The 65100516121 from Wurth Elektronik is a surface mount, WR-COM mini USB 2.0 type B socket with right angle mounting. USB 2.0 interface supports data transfer rate of up to 480Mbit/s.
Black colour LCP insulator
Rated current is 1A
Rated voltage is 30VAC
Maximum contact resistance is 20mohm
Copper alloy with gold plated contacts
Brass with nickel plated shell
Operating temperature range from -40°C to 105°C
UL / cULus E323964 certified

expand all
