7022AE ,Time Delay Relay, Timing Relay - TE Connectivity
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
65 points
-
Part No7022AE
-
ManufacturerTE Connectivity
-
ChipWorker Part#CW85104172
-
CategoryTime Delay Relay, Timing Relay
-
DescriptionTime Delay Relay 110V/120VAC 10A DPDT (( 114.8mm 82.6mm 78.5mm)) Panel Mount
-
DocumentationDatasheet
-
Ships fromMoscow
-
Наличие1000 pcs In Stock
-
Estimated Price$ 437.53
