70-IDC24 ,I/O Module - Grayhill

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

87 points

Part No

70-IDC24
Manufacturer

Grayhill
ChipWorker Part#

CW24268900
Category

I/O Module
Package

Module
Description

Relay SSR 18mA 32V DC-IN 0.05A 50V DC-OUT 5Pin
Documentation

Datasheet
Ships from

Moscow
Наличие

4 pcs In Stock
Estimated Price

$ 9.14

Buy 70-IDC24

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

70-IDC24 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

70-IDC24 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	70-IDC24
Manufacturer	Grayhill
ChipWorker Part#	CW24268900
Category	I/O Module
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	5 Pin
Case/Package	Module
Supply Voltage (DC)	24.0 V
Current Rating	18 mA
Output Voltage	24 V
Output Current	0.05 A
Contacts Type	SPST-NO
Input Current	18 mA
Input Voltage (Max)	32 VDC
Input Voltage (Min)	3 VDC
Input Current (Min)	18 mA
Number of Digital Outputs	1 Output
Load Current (Max)	50 mA
Operating Temperature (Max)	100 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	24 VDC
Input Voltage	32 V
	expand all
Size-Length	43.2 mm
Color	White
Operating Temperature	-40℃ ~ 100℃
Product Lifecycle Status	Not Recommended for New Design
Packaging	Bulk
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance Edition	2016/06/20
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

Grayhill offers standard, mini, and G5 sized digital I/O modules, compatible with its industrial control and data acquisition products. Our line of pluggable input and output modules provide a versatile method for interconnecting real world digital signals to data acquisition, monitoring, or control systems. All modules provide an optically isolated barrier between sensitive microprocessor or digital logic circuits and field power devices. In the G5 and OpenLine® packages, I/O modules are available with the same pin-out. This gives the flexibility of mixing and matching module types on the same mounting rack or base; making them perfect in applications which require interface to a variety of different sensors and loads.
The case color of the single point modules identify their function. The industry standard for single point I/O module case colors is: Digital AC output module = black case; Digital DC output module = red case; Digital AC input module = yellow case; Digital DC input module = white case.
* G5 Refusible Module with Integral LED
* UL Recognized and CSA Certified
* Meets IEEE 472-1974 and ANSI C37.90 Noise Immunity Standards
* Surface-Mount Internal Construction Provides Excellent High Thermal Conductivity
