74AC138PC - Fairchild

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

74AC138PC
Manufacturer

Fairchild
ChipWorker Part#

CW102442936
Category

Logic Controller, Logic IC
Package

DIP-16
Description

Decoder/Demultiplexer Single 3-to-8 16Pin PDIP Rail
Documentation

Datasheet

74AC138PC Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

74AC138PC Specifications

Attribute	Attribute Value

Part Number	74AC138PC
Manufacturer	Fairchild
ChipWorker Part#	CW102442936
Category	Logic Controller, Logic IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	DIP-16
Supply Voltage (DC)	2.00V (min)
Number of Outputs	8 Output
Output Current	5.5 mA
Number of Circuits	1 Circuit
Number of Gates	1 Gate
Output Current (Max)	24 mA
Number of Inputs	3 Input
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	2V ~ 6V
Supply Voltage (Max)	6 V
Supply Voltage (Min)	2 V
	expand all
Size-Length	19.68 mm
Size-Width	6.6 mm
Size-Height	4.95 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Unknown
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

General Description
The AC/ACT138 is a high-speed 1-of-8 decoder/demultiplexer. This device is ideally suited for high-speed bipolar memory chip select address decoding. The multiple input enables allow parallel expansion to a 1-of-24 decoder using just three AC/ACT138 devices or a 1-of-32 decoder using four AC/ACT138 devices and one inverter.
Features
■ ICC reduced by 50%
■ Demultiplexing capability
■ Multiple input enable for easy expansion
■ Active LOW mutually exclusive outputs
■ Outputs source/sink 24 mA
