A000062 - Arduino

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

A000062
Manufacturer

Arduino
ChipWorker Part#

CW3168707
Category

Microprocessor Primary Platform
Package

Module
Description

AT91SAM3X8E Microcontroller Development Board 84MHz CPU 96KB RAM
Documentation

Datasheet

A000062 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

A000062 Specifications

Attribute	Attribute Value

Part Number	A000062
Manufacturer	Arduino
ChipWorker Part#	CW3168707
Category	Microprocessor Primary Platform
Documentation	Datasheet
Case/Package	Module
RAM Memory Size	96 KB
Number of Bits	32 Bit
Core Architecture	ARM
Core Sub-Architecture	Cortex-M3
	expand all
Product Lifecycle Status	Active
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC

Product Description

The A000062 is an Arduino Due development board based on the Atmel AT91SAM3X8E ARM Cortex-M3 microcontroller. It is the first Arduino board based on a 32bit ARM core microcontroller. It has 54 digital input/output pins (of which 12 can be used as PWM outputs), 12 analog inputs, 4 UARTs (hardware serial ports), a 84MHz clock, an USB OTG capable connection, two DAC (digital to analog), two TWI, a power jack, an SPI header, a JTAG header, a reset button and an erase button. The board contains everything needed to support the microcontroller, simply connect it to a computer with a micro USB cable or power it with a AC to DC adapter or battery to get started. The Due is compatible with all Arduino shields that work at 3.3V and are compliant with the 1.0 Arduino pinout. The Arduino Due can be powered via the USB connector or with an external power supply. The power source is selected automatically.
Input voltage (recommended) range from 7V to 12V
3.3V operating voltage
96KB of SRAM
130mA of total DC output current per I/O lines
Input voltage (limit) range from 6V to 20V
The Arduino Due can be programmed with the Arduino software
The maximum length and width of the Arduino Due PCB are 4inch and 2.1inch respectively
1.0 pinout
A DMA controller, that can relieve the CPU from doing memory intensive tasks
512KB of flash memory for code
The Arduino Due board runs at 3.3V. The maximum voltage that the I/O pins can tolerate is 3.3V. Providing higher voltages, like 5V to an I/O pin could damage the board.
