AD569JN - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD569JN
Manufacturer

ADI
ChipWorker Part#

CW36029164
Category

Digital to Analog, DAC IC
Package

PDIP-28
Description

DAC 1CH Resistor-String 16Bit 28Pin PDIP W Tube
Documentation

Datasheet

AD569JN Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD569JN Specifications

Attribute	Attribute Value

Part Number	AD569JN
Manufacturer	ADI
ChipWorker Part#	CW36029164
Category	Digital to Analog, DAC IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	28 Pin
Case/Package	PDIP-28
Number of Bits	16 Bit
Power Dissipation	1000 mW
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	1000 mW
Number of DACs	1 DAC
	expand all
Size-Height	4.95 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
ECCN Code	EAR99

Product Description

If you are looking for a way to convert a digital stream of data into a perceptible analog signal, Analog Devices brings you their AD569JN DAC converter as a solution. It has a voltage output. This device is based on Resistor-String architecture. This device"s digital interface is parallel. This DAC has a resolution of 16bit. Its typical dual supply voltage is ±12 V, with a minimum of ±10.8 V and maximum of ±13.2 V. This DAC has a minimum operating temperature of 0 °C and a maximum of 70 °C. This device comes in tube packaging. This device uses dual power supplies.
