AD571SD - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD571SD
Manufacturer

ADI
ChipWorker Part#

CW2085000
Category

Analog to Digital, ADC IC
Package

CDIP-18
Description

IC,A/D CONVERTER,SINGLE,10Bit,BIPOLAR,DIP,18Pin
Documentation

Datasheet

AD571SD Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD571SD Specifications

Attribute	Attribute Value

Part Number	AD571SD
Manufacturer	ADI
ChipWorker Part#	CW2085000
Category	Analog to Digital, ADC IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	18 Pin
Case/Package	CDIP-18
Digital Logic Level	SAR
Number of Channels	1 Channel
Number of Bits	10 Bit
Power Dissipation	800 W
Sample Rate	25 ksps
Resolution (Bits)	10.0 Bit
Number of ADCs	1 ADC
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	275 mW
Number of Input Channels	1 Channel
	expand all
Size-Length	23.12 mm
Size-Width	7.62 mm
Size-Height	3.05 mm
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
Mil-Spec	Yes
ECCN Code	3A001.a.2.c

Product Description

This AD571SD ADC from Analog Devices uses a transducer to convert real world physical signals into analog electrical signals before it converts analog signals to digital data. This device"s digital interface is parallel. It has a single-ended input signal. Its maximum power dissipation is 800 mW. This device is based on SAR architecture. This ADC has a resolution of 10bit. This ADC has an input voltage of 10 V|±5V. Its typical dual supply voltage is -15/5 V, with a minimum of -12/4.5 V and maximum of -16.5/7 V. This ADC has a minimum operating temperature of -55 °C and a maximum of 125 °C.
