ZEN065V130A24LS - Littelfuse

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ZEN065V130A24LS
Manufacturer

Littelfuse
ChipWorker Part#

CW36079240
Category

Zener Diode, Zener
Package

SMD-3
Description

LITTELFUSE ZEN065V130A24LS Zener Single Diode, 6.5V, 700mW, SMD, 3Pins, 85℃
Documentation

Datasheet

ZEN065V130A24LS Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ZEN065V130A24LS Specifications

Attribute	Attribute Value

Part Number	ZEN065V130A24LS
Manufacturer	Littelfuse
ChipWorker Part#	CW36079240
Category	Zener Diode, Zener
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SMD-3
Capacitance	4200 pF
Number of Circuits	1 Circuit
Power Dissipation	700 mW
Clamping Voltage	24 V
Test Current	100 mA
Max Breakdown Voltage	6.65 V
Zener Voltage	6.5 V
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
	expand all
Size-Length	4.15 mm
Size-Width	4.15 mm
Size-Height	1.7 mm
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99
