AD7441BRTZ-REEL7 ,Analog to Digital, ADC IC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

90 points

Part No

AD7441BRTZ-REEL7
Manufacturer

ADI
ChipWorker Part#

CW77771162
Category

Analog to Digital, ADC IC
Package

SOT-23-8
Description

Single ADC SAR 1MSPS 10Bit Serial 8Pin SOT-23 T/R
