AD7652 Specifications

Attribute	Attribute Value

Part Number	AD7652
Manufacturer	ADI
ChipWorker Part#	CW389426490
Documentation	Datasheet
	expand all
Product Lifecycle Status	Active

Product Description

Product Details
The AD7652 is a 16-bit, 500 kSPS, charge redistribution SAR, analog-to-digital converter that operates from a single 5 V power supply. The part contains a high-speed 16-bit sampling ADC, an internal conversion clock, internal reference, error correction circuits, and both serial and parallel system interface ports.
It is fabricated using Analog Devices" high-performance, 0.6 micron CMOS process, with correspondingly low cost and is available in a 48-lead LQFP and a tiny 48-lead LFCSP with operation specified from -40°C to +85°C.
**APPLICATIONS**
Data acquisition
Instrumentation
Digital signal processing
Spectrum analysis
Medical instruments
Battery-powered systems
Process control
### Features and Benefits
2.5 V Internal Reference:
Typical Drift 7 ppm/ºC
Throughput: 500 kSPS
16-Bit Resolution
Analog Input Voltage Range: 0 V to 2.5 V
No Pipeline Delay
Parallel and Serial 5 V/3 V Interface
SPI®/QSPI™/MICROWIRE™/DSP Compatible
Single 5 V Supply Operation
Power Dissipation:
65 mW typ, 130 µW
@ 1 kSPS without REF
80 mW typ with REF
Package:
48-Lead Quad Flat Pack (LQFP)
48-Lead Chip Scale Package (LFCSP)
Pin-to-Pin Compatible with PulSAR™ ADCs
