AD8042AR ,Operational Amplifier, OP Amp IC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

172 points

Part No

AD8042AR
Manufacturer

ADI
ChipWorker Part#

CW16612938
Category

Operational Amplifier, OP Amp IC
Package

SOIC-8
Description

OP Amp Dual Volt Fdbk R-R O/P 6V/12V 8Pin SOIC N Tube
Documentation

Datasheet
Ships from

Moscow
Наличие

611 pcs In Stock
Estimated Price

$ 4.15

Buy AD8042AR

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

AD8042AR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

AD8042AR Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	AD8042AR
Manufacturer	ADI
ChipWorker Part#	CW16612938
Category	Operational Amplifier, OP Amp IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Current	6 mA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Power Dissipation	900 mW
Common Mode Rejection Ratio	68 dB
Input Capacitance	1.50 pF
Slew Rate	200 V/μs
Gain Bandwidth Product	90 MHz
Input Impedance	300 kΩ
Input Offset Voltage	3 mV
Input Bias Current	1.2 µA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	170 MHz
Power Dissipation (Max)	900 mW
Minimum CMRR Range	68 dB
Supply Voltage (Max)	12 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
Mil-Spec	No
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

Product Details
The AD8042 is a low power voltage feedback, high speed amplifier designed to operate on +3 V, +5 V or ± 5 V supplies. It has true single supply capability with an input voltage range extending 200 mV below the negative rail and within 1 V of the positive rail.
The output voltage swing extends to within 30 mV of each rail, providing the maximum output dynamic range. Additionally, it features gain flatness of 0.1 dB to 14 MHz while offering differential gain and phase error of 0.04% and 0.06° on a single 5 V supply. This makes the AD8042 useful for professional video electronics such as cameras, video switchers or any high speed portable equipment. The AD8042"s low distortion and fast settling make it ideal for buffering single-supply, high speed Analog-to-Digital converters (ADCs).
The AD8042 offers low power supply current of 12 mA maximum and can run on a single 3.3 V power supply. These features are ideally suited for portable and battery powered applications where size and power are critical.
The wide bandwidth of 160 MHz along with 200 V/µs of slew rate on a single 5 V supply make the AD8042 useful in many general-purpose, high speed applications where single supplies from +3.3 V to +12 V and dual power supplies of up to ±6 V are needed. The AD8042 is available in 8-lead PDIP and SOIC_N packages.
**Applications**
Video switchers
Distribution amplifiers
Analog-to-digital drivers
Professional cameras
CCD Imaging systems
Ultrasound equipment (multichannel)
### Features and Benefits
Single AD8041 and quad AD8044 also available
Fully specified at +3 V, +5 V, and ±5 V supplies
Output swings to within 30 mV of either rail
Input voltage range extends 200 mV below ground
High speed and fast settling on 5 V:
160 MHz –3 dB bandwidth (G = +1)
200 V/µs slew rate
39 ns settling time to 0.1%
Drives 50 mA 0.5 V from supply rails
No phase reversal with inputs 0.5 V beyond supplies
Low power of 5.2 mA per amplifier
Good video specifications
(RL = 150 Ω, G = +2)
Gain flatness of 0.1 dB to 14 MHz
0.02% differential gain error
0.04° differential phase error
Low distortion
–64 dBc worst harmonic @ 10 MHz
