AD8065ARZ ,Operational Amplifier, OP Amp IC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

270 points

Part No

AD8065ARZ
Manufacturer

ADI
ChipWorker Part#

CW147904
Category

Operational Amplifier, OP Amp IC
Package

SOIC-8
Description

ANALOG DEVICES AD8065ARZ Operational Amplifier, Single, 1 Amplifier, 145MHz, 180V/µs, 5V to 24V, SOIC, 8Pins
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 4.6

Buy AD8065ARZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

AD8065ARZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

AD8065ARZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	AD8065ARZ
Manufacturer	ADI
ChipWorker Part#	CW147904
Category	Operational Amplifier, OP Amp IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Current	6.6 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	100 dB
Input Capacitance	2.10 pF
Bandwidth	145 MHz
Slew Rate	180 V/μs
Gain Bandwidth Product	155 MHz
Input Impedance	1.00 TΩ
Gain	1.00 dB
Input Offset Voltage	400 µV
Input Bias Current	3 pA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	145 MHz
Minimum CMRR Range	74 dB
Supply Voltage	5V ~ 24V
Supply Voltage (Max)	24 V
Supply Voltage (Min)	5 V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The AD8065ARZ is a 145MHz High Performance Single FastFET™ Operational Amplifier with FET inputs offering high performance and ease of use. It is a single voltage feedback amplifier that provides excellent overall performance. With a wide supply voltage range from 5 to 24V, the ability to operate on single supplies and a bandwidth of 145MHz, the AD8065 is designed to work in a variety of applications. For added versatility, the amplifiers also contain rail-to-rail outputs. The amplifier is developed in the proprietary XFCB process and allows exceptionally low noise operation (7.0nV/√Hz and 0.6fA/√Hz) as well as very high input impedance.
1pA Input bias current
High speed
Low noise
1.5mV Maximum low offset voltage
-100dB High common-mode rejection ratio
-88dBc SFDR at 1MHz
Low power
6.4mA/amplifier Typical supply current
No phase reversal
ESD sensitive device, take proper precaution while handling the device.
