AD8206YRZ ,Operational Amplifier, OP Amp IC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

209 points

Part No

AD8206YRZ
Manufacturer

ADI
ChipWorker Part#

CW750600
Category

Operational Amplifier, OP Amp IC
Package

SOIC-8
Description

ANALOG DEVICES AD8206YRZ Differential Amplifier, Bidirectional, 1 Amplifiers, 2mV, 20dB, 100kHz, -40℃, 125℃
Documentation

Datasheet
Ships from

Moscow
Наличие

539594 pcs In Stock
Estimated Price

$ 0.01

Buy AD8206YRZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

AD8206YRZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

AD8206YRZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	AD8206YRZ
Manufacturer	ADI
ChipWorker Part#	CW750600
Category	Operational Amplifier, OP Amp IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Supply Voltage (DC)	4.50V (min)
Supply Current	2 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	76 dB
Bandwidth	100 kHz
Slew Rate	50.0 mV/μs
Gain Bandwidth Product	0.1 MHz
Input Offset Voltage	2 mV
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	100 kHz
Gain Bandwidth	76 dB
Minimum CMRR Range	76 dB
Supply Voltage	4.5V ~ 5.5V
Supply Voltage (Max)	5V ~ 7V
Supply Voltage (Min)	4.5 V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The AD8206YRZ is a High Common-mode Voltage Bidirectional Current Shunt Amplifier operating input common-mode voltage range extends from -2 to +65V. The typical single-supply voltage is 5V. Excellent DC performance over-temperature keeps errors in the measurement loop to a minimum. Offset drift is typically less than 15µV/°C and gain drift is typically below 30ppm/°C. The output offset can be adjusted from 0.08 to 4.7V with a 5V supply by using the VREF1 and VREF2 pins. With VREF1 attached to the V+ pin and VREF2 attached to the GND pin, the output is set at half scale. Attaching both pins to GND causes the output to be unipolar, starting near ground. Attaching both pins to V+ causes the output to be unipolar starting near V+. Other offsets can be obtained by applying an external voltage to the VREF1 and VREF2 pins.
Ideal for current shunt applications
High common-mode voltage range
Bidirectional operation
15µV/°C Offset drift
30ppm/°C Gain drift
80dB CMRR DC to 20kHz
