AD830ARZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD830ARZ
Manufacturer

ADI
ChipWorker Part#

CW462859
Category

Video Amplifier, CATV Amplifier IC
Package

SOIC-8
Description

ANALOG DEVICES AD830ARZ Video Amplifier, 2 Amplifiers, 85MHz, 360V/µs, -40℃, 85℃, 50mA
Documentation

Datasheet

AD830ARZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD830ARZ Specifications

Attribute	Attribute Value

Part Number	AD830ARZ
Manufacturer	ADI
ChipWorker Part#	CW462859
Category	Video Amplifier, CATV Amplifier IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Output Current	50 mA
Supply Current	14.5 mA
Number of Circuits	1 Circuit
Number of Channels	1 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	90 dB
Quiescent Current	14.5 mA
Bandwidth	85 MHz
Slew Rate	360 V/μs
Gain Bandwidth Product	85 MHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
3dB Bandwidth	85 MHz
Gain Bandwidth	85 MHz
Supply Voltage (Max)	33 V
Supply Voltage (Min)	8 V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Product Description

The AD830ARZ is a wideband Differencing Amplifier designed for use at video frequencies but also useful in many other applications. It accurately amplifies a fully differential signal at the input and produces an output voltage referred to user-chosen level. The undesired common-mode signal is rejected, even at high frequencies. High impedance input ease interfacing to finite source impedances and thus preserve the excellent common-mode rejection. In many respects, it offers significant improvements over discrete difference amplifier approaches, in particular in high frequency common-mode rejection. The wide common-mode and differential-voltage range of the AD830 make it particularly useful and flexible in level shifting applications, but at lower power dissipation than discrete solutions. Low distortion is preserved over the many possible differential and common-mode voltages at the input and output.
Differential amplification
Symmetrical dynamic response
Fast dynamic performance
Flexible operation
±2V Differential voltage
60dB at 4MHz High CMRR
±2.3V Built-in differential clipping level
35ns Settling time to 0.1%
3mV Maximum input offset voltage
