AD8572ARUZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD8572ARUZ
Manufacturer

ADI
ChipWorker Part#

CW321813
Category

Amplifier, Buffer IC
Package

TSSOP-8
Description

ANALOG DEVICES AD8572ARUZ Operational Amplifier, Dual, 2 Amplifier, 1.5MHz, 0.5V/µs, 2.7V to 5.5V, TSSOP, 8Pins
Documentation

Datasheet

AD8572ARUZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD8572ARUZ Specifications

Attribute	Attribute Value

Part Number	AD8572ARUZ
Manufacturer	ADI
ChipWorker Part#	CW321813
Category	Amplifier, Buffer IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	TSSOP-8
Supply Current	850 µA
Number of Circuits	2 Circuit
Number of Channels	2 Channel
Number of Positions	8 Position
Common Mode Rejection Ratio	120 dB
Bandwidth	1.5 MHz
Slew Rate	500 mV/μs
Gain Bandwidth Product	1.5 MHz
Input Impedance	1.00 TΩ
Input Offset Voltage	1 µV
Input Bias Current	10 pA
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Gain Bandwidth	1.5 MHz
Minimum CMRR Range	120 dB
Supply Voltage	2.7V ~ 5.5V
	expand all
Size-Length	3 mm
Size-Width	4.4 mm
Size-Height	1.05 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2015/12/17

Product Description

Product Details
This family of amplifiers has ultralow offset, drift, and bias current. The AD8571, AD8572, and AD8574 are single, dual, and quad amplifiers, respectively, featuring rail-to-rail input and output swings. All are guaranteed to operate from 2.7 V to 5 V single supply.
The AD8571/AD8572/AD8574 provide benefits previously found only in expensive auto-zeroing or chopper-stabilized amplifiers. Using Analog Devices, Inc., topology, these zero-drift amplifiers combine low cost with high accuracy. (No external capacitors are required.) Using a patented spread-spectrum, auto-zero technique, the AD8571/AD8572/AD8574 eliminate the intermodulation effects from interaction of the chopping function with the signal frequency in ac applications.
With an offset voltage of only 1 μV and drift of 0.005 μV/°C, the AD8571/AD8572/AD8574 are perfectly suited for applications where error sources cannot be tolerated. Position and pressure sensors, medical equipment, and strain gage amplifiers benefit greatly from nearly zero drift over their operating temperature range. Many more systems require the rail-to-rail input and output swings provided by the AD8571/AD8572/AD8574.
**Applications**
* Temperature sensors
* Pressure sensors
* Precision current sensing
* Strain gage amplifiers
* Medical instrumentation
* Thermocouple amplifiers
### Features and Benefits
Low offset voltage: 1 μV
Input offset drift: 0.005 μV/°C
Rail-to-rail input and output swing
5 V/2.7 V single-supply operation
High gain: 145 dB typical
CMRR: 140 dB typical
PSRR: 130 dB typical
See data sheet for additional information
