AD9789BBCZ - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

AD9789BBCZ
Manufacturer

ADI
ChipWorker Part#

CW519944
Category

Digital to Analog, DAC IC
Package

BGA-164
Description

Digital to Analog Converters - DAC 14B 2400MSPS RF w/ 4CH Signal Process
Documentation

Datasheet

AD9789BBCZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

AD9789BBCZ Specifications

Attribute	Attribute Value

Part Number	AD9789BBCZ
Manufacturer	ADI
ChipWorker Part#	CW519944
Category	Digital to Analog, DAC IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	164 Pin
Case/Package	BGA-164
Number of Outputs	1 Output
Supply Current	45 mA
Number of Channels	1 Channel
Number of Positions	164 Position
Number of Bits	14 Bit
Power Dissipation	1.7 W
Sample Rate	2.40 GHz
Resolution (Bits)	14.0 Bit
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	3.3 V
Supply Voltage (Max)	3.47 V
Supply Voltage (Min)	3.14 V
	expand all
Size-Length	12 mm
Size-Width	12 mm
Size-Height	0.89 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
Mil-Spec	No
REACH SVHC Compliance Edition	2014/06/16
ECCN Code	5A991.b
HK STC License	NLR

Product Description

The AD9789BBCZ is a 14-bit Digital-to-analog Converter (DAC) with 4-channel signal processing. The flexible digital interface can accept up to 4-channel of complex data. The QAM encoder supports constellation sizes of 16, 32, 64, 128 and 256 with SRRC filter coefficients for all standards. The on-chip rate converter supports a wide range of baud rates with a fixed DAC clock. The digital up-converter can place the channels from 0 to 0.5 x fDAC. This permits four contiguous channels to be synthesized and placed anywhere from dc to fDAC/2. The AD9789 includes a serial peripheral interface (SPI) for device configuration and status register read-back. The AD9789 operates from 1.5, 1.8 and 3.3V supplies for a total power consumption of 1.6W. The clock receiver powers up muted to prevent start-up noise.
Can accept real or complex data
No special power sequencing is required
On chip and bypassable
Direct to RF synthesis support with fS mix mode
Built-in self-test (BIST) support
Input connectivity check
Internal random number generator

expand all
