ADCLK846BCPZ-REEL7 ,Clock Buffer, Driver, PLL IC - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

138 points

Part No

ADCLK846BCPZ-REEL7
Manufacturer

ADI
ChipWorker Part#

CW1945407
Category

Clock Buffer, Driver, PLL IC
Package

LFCSP-24
Description

Clock Fanout Buffer 6Out 1IN 1:6 24Pin LFCSP EP T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 4.32

Buy ADCLK846BCPZ-REEL7

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ADCLK846BCPZ-REEL7 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ADCLK846BCPZ-REEL7 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADCLK846BCPZ-REEL7
Manufacturer	ADI
ChipWorker Part#	CW1945407
Category	Clock Buffer, Driver, PLL IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	24 Pin
Case/Package	LFCSP-24
Number of Outputs	6 Output
Number of Circuits	1 Circuit
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	1.71V ~ 1.89V
Supply Voltage (Max)	1.89 V
Supply Voltage (Min)	1.71 V
	expand all
Size-Width	4 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

Product Details
The ADCLK846 is a 1.2 GHz/250 MHz, LVDS/CMOS, fanout buffer optimized for low jitter and low power operation. Possible configurations range from 6 LVDS to 12 CMOS outputs, including combinations of LVDS and CMOS outputs. Two control lines are used to determine whether fixed blocks of outputs are LVDS or CMOS outputs.
The clock input accepts various types of single-ended and differential logic levels including LVPECL, LVDS, HSTL, CML, and CMOS.
Table 8 provides interface options for each type of connection. The SLEEP pin enables a sleep mode to power down the device.
This device is available in a 24-pin LFCSP package. It is specified for operation over the standard industrial temperature range of −40°C to +85°C.
**Applications**
Low jitter clock distribution
Clock and data signal restoration
Level translation
Wireless communications
Wired communications
Medical and industrial imaging
ATE and high performance instrumentation
### Features and Benefits
Selectable LVDS/CMOS outputs
Up to 6 LVDS (1.2 GHz) or 12 CMOS (250 MHz) outputs
<16 mW per channel (100 MHz operation)
54 fs integrated jitter (12 kHz to 20 MHz)
100 fs additive broadband jitter
2.0 ns propagation delay (LVDS)
135 ps output rise/fall (LVDS)
65 ps output-to-output skew (LVDS)
Sleep mode
Pin-programmable control
1.8 V power supply
