ADF5001 Specifications

Attribute	Attribute Value

Part Number	ADF5001
Manufacturer	ADI
ChipWorker Part#	CW353140937
Documentation	Datasheet
	expand all
Product Lifecycle Status	Active
RoHS	RoHS Compliant

Product Description

Product Details
The ADF5001 prescaler is a low noise, low power, fixed RF divider block that can be used to divide down frequencies as high as 18 GHz to a lower frequency suitable for input into a PLL IC, such as the ADF4156 or ADF4106. The ADF5001 provides a divide-by-4 function. The ADF5001 operates off a 3.3 V supply and has differential 100 Ω RF outputs to allow direct interface to the differential RF inputs of PLLs such as the ADF4156 and ADF4106.
**Applications**
* PLL frequency range extender
* Point-to-point radios
* VSAT radios
* Communications test equipment
### Features and Benefits
Divide-by-4 prescaler
High frequency operation: 4 GHz to 18 GHz
Integrated RF decoupling capacitors
Active mode: 30 mA
Power-down mode: 7 mA
Low phase noise: −150 dBc/Hz
Single dc supply: 3.3 V compatible with ADF4xxx PLLs
Temperature range: −40°C to +105°C
Small package: 3 mm × 3 mm LFCSP
