ADP5070ACPZ ,DC to DC Converter - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

153 points

Part No

ADP5070ACPZ
Manufacturer

ADI
ChipWorker Part#

CW628182
Category

DC to DC Converter
Package

LFCSP-20
Description

Conv DC-DC 2.85V to 15V Non-Inv/Inv/Step Up/Step Down Single-Out 2.85V to 39V 20Pin LFCSP EP Tray
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 1.87

Buy ADP5070ACPZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ADP5070ACPZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ADP5070ACPZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADP5070ACPZ
Manufacturer	ADI
ChipWorker Part#	CW628182
Category	DC to DC Converter
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	LFCSP-20
Number of Outputs	2 Output
Output Voltage	2.85V ~ 39V
Output Current	600mA, 1A
Number of Positions	20 Position
Switching Frequency	2.4 MHz
Input Voltage (Max)	15 V
Input Voltage (Min)	2.85 V
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage (Min)	2.85 V
Input Voltage	15 V
	expand all
Size-Height	0.73 mm
Operating Temperature	-40℃ ~ 125℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tray
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

The ADP5070ACPZ is a high performance, dual DC to DC switching regulator with independent positive and negative outputs in 20 pin LFCSP package. The integrated main switch in both regulators enables generation of an adjustable positive output voltage up to +39V and negative output voltages down to -39V below input voltage. The ADP5070 operates at a pin selected 1.2MHz/2.4MHz switching frequency. It can synchronize with an external oscillator from 1MHz to 2.6MHz to ease noise filtering in sensitive applications. Both regulators implement programmable slew rate control circuitry for MOSFET driver stage to reduce EMI. The ADP5070 includes fixed internal or resistor programmable soft start timer to prevent inrush current at power-up. During shutdown, both regulators completely disconnect the loads from the input supply to provide true shutdown. This regulator provides overcurrent protection (OCP), overvoltage protection (OVP), thermal shutdown (TSD) and input undervoltage lockout (UVLO).
Wide input voltage range from 2.85V to 15V
Integrated 1A main switch for boost regulator and 0.6A main switch for inverting regulator
Supported by the ADIsimPower tool set
Boost regulator to generate VPOS output and inverting regulator to generate VNEG output
Out of phase operation
Individual precision enable and flexible start-up sequence
Slew rate control for lower system noise
Resistor programmable soft start timer
Optional single ended primary inductor converter (SEPIC)
Operating junction temperature range from -40°C to 125°C
ESD (electrostatic discharge) sensitive device. Proper ESD precautions are recommended to avoid performance degradation or loss of functionality.
