ADS7846E ,Active Chip - TI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

205 points

Part No

ADS7846E
Manufacturer

TI
ChipWorker Part#

CW5047515
Category

Active Chip
Package

SSOP-16
Description

TOUCH SCREEN CONTROLLER IC, Resistive Touch Screen, 12Bit, Supply Voltage Range:2.7V to 5.25V; Operating Temperature Range:-40C to +85C, SSOP-16
Documentation

Datasheet
Ships from

Moscow
Наличие

62 pcs In Stock
Estimated Price

$ 2.99

Buy ADS7846E

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

ADS7846E Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

ADS7846E Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	ADS7846E
Manufacturer	TI
ChipWorker Part#	CW5047515
Category	Active Chip
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SSOP-16
Supply Voltage (DC)	2.70V (min)
Supply Current	500 µA
Number of Channels	6 Channel
Number of Positions	16 Position
Number of Bits	12 Bit
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	2.2V ~ 5.25V
Supply Voltage (Max)	5.25 V
Supply Voltage (Min)	2.7 V
	expand all
Size-Length	5 mm
Size-Width	4 mm
Size-Height	1.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

DESCRIPTION
The ADS7846 is a next-generation version to the industry standard ADS7843 4-wire touch screen controller. The ADS7846 is 100% pin-compatible with the existing ADS7843, and drops into the same socket. This allows for easy upgrade of current applications to the new version. Only software changes are required to take advantage of the added fea tures of direct battery measurement, temperature measurement, and touch-pressure measurement. The ADS7846 also
has an on-chip 2.5V reference that can be used for the auxiliary input, battery monitor, and temperature measurement modes. The reference can also be powered down when not used to conserve power. The internal reference operates down to 2.7V supply voltage while monitoring the battery voltage from 0V to 6V.
FEATURES
●SAME PINOUT AS ADS7843
●2.2V TO 5.25V OPERATION
●INTERNAL 2.5V REFERENCE
●DIRECT BATTERY MEASUREMENT (0V to 6V)
●ON-CHIP TEMPERATURE MEASUREMENT
●TOUCH-PRESSURE MEASUREMENT
●QSPI™/SPI™ 3-WIRE INTERFACE
●AUTO POWER-DOWN
●TSSOP-16, SSOP-16, QFN-16, AND VFBGA-48 PACKAGES
