Part No

ADUM6404ARIZ
Manufacturer

ADI
ChipWorker Part#

CW818733
Category

Interface Isolator, Digital Isolator
Package

SOIC-16
Description

ANALOG DEVICES ADUM6404ARIZ Digital Isolator, 4Channel, 55ns, 3V, 5.5V, WSOIC, 16Pins
Documentation

Datasheet

ADUM6404ARIZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ADUM6404ARIZ Specifications

Attribute	Attribute Value

Part Number	ADUM6404ARIZ
Manufacturer	ADI
ChipWorker Part#	CW818733
Category	Interface Isolator, Digital Isolator
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	SOIC-16
Supply Voltage (DC)	3.00V (min)
Rise/Fall Time	2.5 ns
Output Current	100 mA
Number of Channels	4 Channel
Number of Positions	16 Position
Power Dissipation	400 mW
Rise Time	2.5 ns
Isolation Voltage	5000 Vrms
Input Current (Min)	14 mA
Maximum Forward Voltage (Max)	5.5 V
Fall Time (Max)	2.5 ns
Fall Time (Max)	2.5 ns
Operating Temperature (Max)	105 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	400 mW
Supply Voltage	3V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	13 mm
Size-Width	7.6 mm
Operating Temperature	-40℃ ~ 105℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Product Description

The ADUM6404 series quad-channel Digital Isolator with isoPower® an integrated isolated DC-to-DC converter. Based on the Analog Devices, Inc., iCoupler® technology, the DC-to-DC converter provides up to 400mW of regulated. It eliminates the need for a separate isolated DC-to-DC converter in low power isolated designs. It provides four independent isolation channels in a variety of channel configurations and data rates. The isoPower uses high frequency switching elements to transfer power through its transformer. Special care must be taken during printed circuit board (PCB) layout to meet emissions standards.
