AQZ202 ,Solid State Relay - Panasonic

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

155 points

Part No

AQZ202
Manufacturer

Panasonic
ChipWorker Part#

CW9989593
Category

Solid State Relay
Package

SIP-4
Description

Relay SSR 50mA 1.5V DC-IN 3A 60V AC-DC Output 4Pin SIL
Documentation

Datasheet
Ships from

Moscow
Наличие

216 pcs In Stock
Estimated Price

$ 3.06

Buy AQZ202

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

AQZ202 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

AQZ202 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	AQZ202
Manufacturer	Panasonic
ChipWorker Part#	CW9989593
Category	Solid State Relay
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	4 Pin
Case/Package	SIP-4
Supply Voltage (DC)	3.00 V
Current Rating	3 A
Insulation Resistance	1.00 GΩ
Capacitance	1.5 pF
Power Rating	1.60 W
Output Voltage	0V ~ 60V
Output Current	3000 mA
Contacts Type	SPST-NO
Load Current	3 A
Input Current	50 mA
Power Dissipation	1600 mW
Rise Time	2.46 ms
Isolation Voltage	2.5 kV
Forward Current	1 mA
Input Voltage (Max)	1.5 V
Output Voltage (Max)	60 V
Output Current (Max)	3 A
Input Current (Min)	50 mA
Load Current (Max)	3 A
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	1600 mW
Voltage Rating	60 VAC
Input Voltage	1.16 VDC
	expand all
Size-Length	21 mm
Size-Width	3.5 mm
Size-Height	12.5 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The AQZ202 is a Solid State Relay with SPST-NO contact and through hole terminals. This AQZ-series Power PhotoMOS® 1-form-A high capacity relay features extremely low closed-circuit offset voltage to enable control of low-level analogue signals without distortion. Eliminates the need for a counter electromotive protection diode in the drive circuit on the input side. Eliminates the need for a power supply to drive the power MOSFET.
Controls low-level analogue signals
Low-level off state leakage current
Low thermo electromotive force
Neither noise nor arc at contact
No restriction on mounting direction
1.6W Power dissipation
5/10ms Turn-on and 3ms turn-off maximum time
-40 to 85°C Operating temperature range
