ATV312HU40N4 - Schneider Electric

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

ATV312HU40N4
Manufacturer

Schneider Electric
ChipWorker Part#

CW113502211
Category

Motors, Drive
Description

Frequency converter ALTIVAR ATV312 4kW, 380. . 0.5VAC 3-phase, ATV312HU40N4, Schneider Electric
Documentation

Datasheet

ATV312HU40N4 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

ATV312HU40N4 Specifications

Attribute	Attribute Value

Part Number	ATV312HU40N4
Manufacturer	Schneider Electric
ChipWorker Part#	CW113502211
Category	Motors, Drive
Documentation	Datasheet
Current Rating	13.9 A
Power Rating	4 kW
Output Voltage	≤500 V
Output Current	9.50 A
Output Voltage (Max)	500 V
Voltage Rating	480 V
Supply Voltage	400 V
Supply Voltage (Max)	500 VAC
Supply Voltage (Min)	380 VAC
	expand all
Size-Length	184 mm
Size-Width	140 mm
Size-Height	184 mm
Product Lifecycle Status	Not Recommended for New Design
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

Ideally suited to the needs of Material Handling, Packaging, Food, Beverage, Pump, Fan and other OEM machines, the Altivar 312 Variable Frequency Drive offers the highest overtorque and is the only drive in its class with a remote graphical keypad. The Altivar 312 Drive redefines the concept of “ease of use” by integrating the best-in-class features from the entire family of Altivar Drives into its user interface. This starts with an intuitive rotary wheel for navigation and adjustments, as well as large control buttons on the face of the drive, protected by a snap-lock seal. You can also use advanced features such as the same graphical keypad used with the Altivar 61 and 71 drives, the new LED display of the Altivar 12 drive or even Bluetooth wireless technology and your mobile phone.
**Features:**
* All the Advantages of Altivar 31 Drive
* Excellent Resistance to Harsh Environments (50° C)
* Coated Cards as Standard (IEC 60721-3-3 Classes 3c2 and 3s2)
* Excellent Resistance to Power Supply and Motor Interference
* 0.25 HP to 20 HP
* Single-Phase 200 V to 240 V, Three-Phase 200 V to 240 V, Three-Phase 380 V to 500 V, Three-Phase 525 V to 600 V
* Integrated Class 2 Emc Filter for Radiated and Conducted Emissions
* Din Rail Mounting
