B78108S1104J - Epcos
The pictures are for reference only, and the specific specifications can be found in the product manual.
-
Part NoB78108S1104J
-
ManufacturerEpcos
-
ChipWorker Part#CW87775624
-
CategoryInductor
-
PackageAxial
-
DescriptionRF Choke Drum Core 100uH 5% 100kHz 70Q-Factor Ferrite 370mA 1.7Ω DCR AXL T/R
-
DocumentationDatasheet
