BCV27 - Fairchild

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

BCV27
Manufacturer

Fairchild
ChipWorker Part#

CW7857796
Category

BJT Transistor, BJT
Package

SOT-23-3
Description

BCV Series NPN 350mW 30V 1.2A SMT Darlington Transistor - SOT-23-3
Documentation

Datasheet

BCV27 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

BCV27 Specifications

Attribute	Attribute Value

Part Number	BCV27
Manufacturer	Fairchild
ChipWorker Part#	CW7857796
Category	BJT Transistor, BJT
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	3 Pin
Case/Package	SOT-23-3
Voltage Rating (DC)	30.0 V
Current Rating	1.20 A
Power Rating	350 mW
Number of Positions	3 Position
Polarity	NPN
Power Dissipation	350 mW
Breakdown Voltage (Collector to Emitter)	30 V
hFE Min	20000 @100mA, 5V
Input Power (Max)	350 mW
DC Current Gain (hFE)	20000
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-55 ℃
Gain Bandwidth	220 MHz
Power Dissipation (Max)	350 mW
	expand all
Size-Length	2.92 mm
Size-Width	1.3 mm
Size-Height	0.93 mm
Operating Temperature	-55℃ ~ 150℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99
HK STC License	NLR

Product Description

The BCV27 is a NPN Darlington Transistor designed for applications requiring extremely high current gain at currents to 1A.
Sourced from Process 05
-55 to 150°C Operating junction temperature range
