Part No

DG211CJ+
Manufacturer

Maxim Integrated
ChipWorker Part#

CW35289800
Category

Analog Switch Ic, Analog Switch Multiplexer
Package

DIP-16
Description

MAXIM INTEGRATED PRODUCTS DG211CJ+.. Analogue Switch, Quad Channel, SPST, 4Channels, 175Ω, ± 4.5V to ± 18V, DIP, 16Pins
Documentation

Datasheet

DG211CJ+ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

DG211CJ+ Specifications

Attribute	Attribute Value

Part Number	DG211CJ+
Manufacturer	Maxim Integrated
ChipWorker Part#	CW35289800
Category	Analog Switch Ic, Analog Switch Multiplexer
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	DIP-16
Supply Voltage (DC)	25.0V (max)
Contacts Type	SPST
Number of Circuits	4 Circuit
Number of Channels	4 Channel
Number of Positions	16 Position
Drain to Source Resistance (on) (Rds)	175 Ω
Number of Bits	4 Bit
Power Dissipation	842 mW
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	842 mW
	expand all
Size-Length	19.43 mm
Size-Width	7.87 mm
Size-Height	4.45 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Unknown
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/06/15

Product Description

4 Circuit IC Switch 1:1 175Ohm 16-PDIP
