Part No

DM163022
Manufacturer

Microchip
ChipWorker Part#

CW59963830
Category

Microprocessor Primary Platform
Description

PIC16F/PIC16F1/PIC18 Microcontroller Demonstration Board 0.032768MHz/2MHz/4MHz CPU 32KB Serial EEPROM
Documentation

Datasheet

DM163022 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

DM163022 Specifications

Attribute	Attribute Value

Part Number	DM163022
Manufacturer	Microchip
ChipWorker Part#	CW59963830
Category	Microprocessor Primary Platform
Documentation	Datasheet
Number of Bits	8 Bit
Core Architecture	PIC
Core Sub-Architecture	PIC18
	expand all
Product Lifecycle Status	Unknown
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance Edition	2015/12/17
HK STC License	NLR

Product Description

The DM163022 is a PICDEM 2 Plus demonstration board. The PICDEM 2 Plus demonstration board is a simple board that demonstrates the capabilities of microchip"s 8bit, 18 pin, 28 pin and 40 pin PIC16FXXX, PIC16F1XXX, and PIC18 devices. The PICDEM 2 Plus demonstration board can be used stand alone with a programmed part, with an in circuit emulator (for example, MPLAB REAL ICE) or with an in circuit programmer/debugger (such as MPLAB ICD 3 or PICkit 3). Sample programs are provided to demonstrate the unique features of the supported devices.
The 18 pin, 28 pin and 40 pin DIP sockets
On board, 5V regulator for direct input from 9V, 100mA AC/DC wall adapter or 9V battery
RS 232 socket and associated hardware for direct connection to an RS 232 interface
Programmer/debugger connectivity supporting MPLAB ICD 3, MPLAB REAL ICE and PICkit 3
PICkit serial connector for analysis of serial communications peripherals such as SPI or I2C
5KR pot for devices with analog inputs
Power on indicator LED
Four LEDs connected to PORTB
