MA330020 - Microchip

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

MA330020
Manufacturer

Microchip
ChipWorker Part#

CW69799600
Category

Microprocessor Development Kit
Description

MICROCHIP MA330020 Evaluation Board, dsPIC33F, 44Pin QFN to 100P Plug In Module
Documentation

Datasheet

MA330020 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

MA330020 Specifications

Attribute	Attribute Value

Part Number	MA330020
Manufacturer	Microchip
ChipWorker Part#	CW69799600
Category	Microprocessor Development Kit
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	44 Pin
	expand all
Product Lifecycle Status	Unknown
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Product Description

The MA330020 Plug In Module is small circuit board used with the Explorer 16 Development Board and the PICtail Plus daughter boards to evaluate dsPIC33FJ16GS504 MCU. The dsPIC33FJ16GS504 is a high performance 16bit Digital Signal Controller within a small 44 pin QFN package. The dsPIC33FJ16GS504 is equipped with Peripheral Pin Select (PPS), the PIM takes advantage of the PPS by using zero ohm resistors to connect the I/O to the 100 pin Explorer 16 Development Board. These plug into the main processor socket of the development boards so that different microcontrollers can be used for prototyping, demonstration or development quickly and easily.
Code efficient (C and Assembly) architecture
High Speed PWM
UART module (12.5Mbps)
4 wire SPI module
I2C module (up to 1 Mbaud) with SMBus support
PPS to allow function remap
Works with Explorer 16 board (DM240001 or DM240002) sold separately
