DS1216D - Maxim Integrated

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

DS1216D
Manufacturer

Maxim Integrated
ChipWorker Part#

CW97343190
Category

Real Time Clock IC
Package

DIP-32
Description

Real Time Clock Phantom Clock/Parallel 32Kbyte Clock/Calendar/ROM Control 32Pin PDIP W
Documentation

Datasheet

DS1216D Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

DS1216D Specifications

Attribute	Attribute Value

Part Number	DS1216D
Manufacturer	Maxim Integrated
ChipWorker Part#	CW97343190
Category	Real Time Clock IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	32 Pin
Case/Package	DIP-32
Supply Voltage (DC)	5.00 V
Number of Positions	32 Position
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Supply Voltage	4.5V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
	expand all
Size-Length	41.14 mm
Size-Width	18.29 mm
Size-Height	11.94 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
REACH SVHC Compliance Edition	2015/06/15

Product Description

GENERAL DESCRIPTION
The DS1216 SmartWatch RAM and SmartWatch ROM sockets are 600-mil-wide DIP sockets with a built-in CMOS watch function, an NV RAM controller circuit, and an embedded lithium energy
source. The sockets provide an NV RAM solution for memory sized from 2K x 8 to 512K x 8 with
package sizes from 26 pins to 32 pins. When a socket is mated with a CMOS SRAM, it provides a
complete solution to problems associated with memory volatility and uses a common energy source to maintain time and date.
FEATURES
 Keeps Track of Hundredths of Seconds, Seconds, Minutes, Hours, Days, Date of the Month, Months, and Years
 Converts Standard 2K x 8 Up to 512K x 8 CMOS Static RAMs into Nonvolatile Memory
 Embedded Lithium Energy Cell Maintains Watch Information and Retains RAM Data
 Watch Function is Transparent to RAM Operation
 Automatic Leap Year Compensation Valid Up to 2100
 Lithium Energy Source is Electrically Disconnected to Retain Freshness Until Power is Applied for the First Time
 Proven Gas-Tight Socket Contacts
 Full ±10% Operating Range
 Accuracy Better Than ±1 Minute/Month at +25°C
