FH19SC-15S-0.5SH(05) ,Connector - Hirose Electric

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

74 points

Part No

FH19SC-15S-0.5SH(05)
Manufacturer

Hirose Electric
ChipWorker Part#

CW76459736
Category

Connector
Description

Conn FFC/FPC Connector SKT 15POS 0.5mm Solder RA SMD T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 0.82

Buy FH19SC-15S-0.5SH(05)

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

FH19SC-15S-0.5SH(05) Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

FH19SC-15S-0.5SH(05) Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	FH19SC-15S-0.5SH(05)
Manufacturer	Hirose Electric
ChipWorker Part#	CW76459736
Category	Connector
Documentation	Datasheet
Mounting Style	Surface Mount
Pin Pitch	500 µm
Number of Contacts	15 Contact
Gender	Female
Contact Plating	Gold
Current Rating	0.5 A
Insulation Resistance	>500MΩ @100VDC
Number of Rows	1 Row
Number of Positions	15 Position
Contact Resistance	<100mΩ @1mA
Number of Mating Cycles	20 Cycle
Voltage Rating	50 V
	expand all
Size-Length	9.5 mm
Size-Width	3 mm
Size-Height	0.93 mm
Housing Color	Beige
Contact Material	Phosphor Bronze
Operating Temperature	-55℃ ~ 85℃
Housing Material	Plastic
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2014/06/16

Similar & Replacement Parts

Similar products

Product Description

The FH19SC series FFC/FPC Board Connector with SMT horizontal mounting type termination. The bottom surface of the connector is solid, without any exposure of the contact. The rotating actuator permits easy insertion and reliable connection with the FPC and FFC. Tactile sensation confirms complete mechanical locking of the actuator and the electrical connection. The connector will also terminate with 0.2 and 0.3mm thick flat flexible cable (FFC).
Conductive traces on the PCB can run under the connector
Low profile, high density and high reliability
Proven flip-lock actuator system assures easy and reliable operation
0.5A Rated current
50VAC Rated voltage
