FSM103 - TE Connectivity

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

FSM103
Manufacturer

TE Connectivity
ChipWorker Part#

CW34750803
Category

Tactile Switch, Jog Switch
Description

ALCOSWITCH - TE CONNECTIVITY FSM103 Tactile Switch, Non Illuminated, 12V, 50mA, 160 gf, Through Hole, FSM Series
Documentation

Datasheet

FSM103 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

FSM103 Specifications

Attribute	Attribute Value

Part Number	FSM103
Manufacturer	TE Connectivity
ChipWorker Part#	CW34750803
Category	Tactile Switch, Jog Switch
Documentation	Datasheet
Mounting Style	Through Hole
Voltage Rating (DC)	24 V
Current Rating	50 mA
Number of Rows	2 Row
Current Rating (Max)	0.05A @24VDC
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-20 ℃
Voltage Rating	24 VDC
Maximum Contact Resistance (Max)	100 mΩ
	expand all
Size-Length	14.1 mm
Size-Height	7.3 mm
Contact Material	Copper Alloy
Operating Temperature	-35℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Bulk
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
HTS Code	8536509065
ECCN Code	EAR99

Product Description

**TE Connectivity FSM Series Tactile Switches**
The professional range of tactile switches from TE Connectivity.
