Part No

FSTD16211MTDX
Manufacturer

Fairchild
ChipWorker Part#

CW14778740
Category

Logic Control, Logic Gate IC
Package

TSSOP-56
Description

FAIRCHILD SEMICONDUCTOR FSTD16211MTDX Bus Switch, 24Channels, 64mA, 4.5V to 5.5V, TSSOP-56
Documentation

Datasheet

FSTD16211MTDX Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

FSTD16211MTDX Specifications

Attribute	Attribute Value

Part Number	FSTD16211MTDX
Manufacturer	Fairchild
ChipWorker Part#	CW14778740
Category	Logic Control, Logic Gate IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	56 Pin
Case/Package	TSSOP-56
Supply Voltage (DC)	5.00 V
Output Current	64 mA
Contacts Type	SPST
Number of Channels	24 Channel
Number of Positions	56 Position
Number of Bits	24 Bit
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	4.5V ~ 5.5V
Supply Voltage (Max)	5.5 V
Supply Voltage (Min)	4.5 V
	expand all
Size-Height	0.95 mm
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Product Description

The FSTD16211MTDX is a 24-bit Bus Switch with level shifting. It provides 24-bits of highspeed CMOS TTL-compatible bus switching. The low On Resistance of the switch allows inputs to be connected to outputs without adding propagation delay or generating additional ground bounce noise. A diode to VCC has been integrated into the circuit to allow for level shifting between 5V inputs and 3.3V outputs. The device is organized as a 12-bit or 24-bit bus switch. When OE1\ is low, the switch is ON and port 1A is connected to port 1B. When OE2\ is low, port 2A is connected to port 2B. When OE1/2\ is high, a high impedance state exists between the A and B ports.
