HCF4098BEY ,Flip Flop IC - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

88 points

Part No

HCF4098BEY
Manufacturer

ST Microelectronics
ChipWorker Part#

CW77766870
Category

Flip Flop IC
Package

DIP-16
Description

4000 Series 3 to 20V Dual Monostable Multivibrator Through Hole - DIP-16
Documentation

Datasheet
Ships from

Moscow
Наличие

1361 pcs In Stock
Estimated Price

$ 3.69

Buy HCF4098BEY

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

HCF4098BEY Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

HCF4098BEY Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	HCF4098BEY
Manufacturer	ST Microelectronics
ChipWorker Part#	CW77766870
Category	Flip Flop IC
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	16 Pin
Case/Package	DIP-16
Supply Voltage (DC)	3.00V (min)
Output Current	6.8 mA
Number of Circuits	2 Circuit
Number of Positions	16 Position
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-55 ℃
Supply Voltage	3V ~ 20V
Supply Voltage (Max)	20 V
Supply Voltage (Min)	3 V
	expand all
Size-Length	20 mm
Size-Width	7.1 mm
Size-Height	4.59 mm
Operating Temperature	-55℃ ~ 125℃
Product Lifecycle Status	Not Recommended for New Designs
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Similar & Replacement Parts

Similar products

Product Description

DESCRIPTION
The HCF4098B is a monolithic integrated circuit fabricated in Metal Oxide Semiconductor technology available in DIP and SOP packages. The HCF4098B dual precision monostable multivibrator provides stable retriggerable/resettable one-shot operation for any fixed voltage timing application.
■ RETRIGGERABLE/RESETTABLE CAPABILITY
■ TRIGGER AND RESET PROPAGATION DELAYS INDEPENDENT OF RX, CX
■ TRIGGERING FROM LEADING OR TRAILING EDGE
■ Q AND Q BUFFERED OUTPUT AVAILABLE
■ SEPARATE RESETS
■ WIDE RANGE OF OUTPUT PULSE WIDTHS
■ QUIESCENT CURRENT SPECIFIED UP TO 20V
■ 5V, 10V AND 15V PARAMETRIC RATINGS
■ INPUT LEAKAGE CURRENT
II = 100nA (MAX) AT VDD = 18V TA = 25°C
■ 100% TESTED FOR QUIESCENT CURRENT
■ MEETS ALL REQUIREMENTS OF JEDEC JESD13B " STANDARD SPECIFICATIONS FOR DESCRIPTION OF B SERIES CMOS DEVICES"
