Part No

HEF40106BT
Manufacturer

NXP
ChipWorker Part#

CW40106132
Category

Logic Control, Logic Gate IC
Package

SOIC-14
Description

NXP HEF40106BT Inverter, Schmitt Trigger, HEF40106, 1Input, 2.4mA, 4.5V to 15.5V, SOIC-14
Documentation

Datasheet

HEF40106BT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

HEF40106BT Specifications

Attribute	Attribute Value

Part Number	HEF40106BT
Manufacturer	NXP
ChipWorker Part#	CW40106132
Category	Logic Control, Logic Gate IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	SOIC-14
Supply Voltage (DC)	4.50V (min)
Output Current	2.4 mA
Number of Positions	14 Position
Number of Gates	6 Gate
Number of Inputs	1 Input
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	-40 ℃
Supply Voltage	4.5V ~ 15.5V
Supply Voltage (Max)	15.5 V
Supply Voltage (Min)	4.5 V
	expand all
Size-Length	8.75 mm
Size-Width	4 mm
Size-Height	1.45 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Unknown
Packaging	Each
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17

Product Description

The HEF40106BT provides six inverting buffers. Each input has a schmitt trigger circuit. The inverting buffer switches at different points for positive going and negative going signals. The difference between the positive voltage (VT+) and the negative voltage (VT-) is defined as hysteresis voltage (VH). The HEF40106BT may be used for enhanced noise immunity or to square up slowly changing waveforms.
Schmitt trigger input discrimination
Fully static operation
Standardised symmetrical output characteristics
