HIP4080AIBZ ,FET Driver - Intersil

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

129 points

Part No

HIP4080AIBZ
Manufacturer

Intersil
ChipWorker Part#

CW29715182
Category

FET Driver
Package

SOIC-20
Description

Intersil HIP4080AIBZ, Quad MOSFET Power Driver 2.5A Full Bridge, 9.5 → 15V, 20Pin SOIC W
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 1

Buy HIP4080AIBZ

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

HIP4080AIBZ Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

HIP4080AIBZ Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	HIP4080AIBZ
Manufacturer	Intersil
ChipWorker Part#	CW29715182
Category	FET Driver
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	SOIC-20
Frequency	1 MHz
Supply Voltage (DC)	9.50 V, 15.0 V (max)
Rise/Fall Time	10 ns
Number of Outputs	4 Output
Output Voltage	86.3 V
Output Current	2.5 A
Number of Channels	4 Channel
Power Dissipation	0.47 W
Rise Time	25 ns
Output Current (Max)	2.5 A
Fall Time	25 ns
Fall Time (Max)	25 ns
Fall Time (Max)	25 ns
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	470 mW
Supply Voltage	9.5V ~ 15V
Supply Voltage (Max)	15 V
Supply Voltage (Min)	9.5 V
	expand all
Size-Length	13 mm
Size-Width	7.6 mm
Size-Height	2.35 mm
Operating Temperature	-40℃ ~ 125℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/06/15
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The HIP4080AIBZ is a high frequency medium voltage Full Bridge N-channel FET Driver IC. The HIP4080A includes an input comparator, used to facilitate the "hysteresis" and PWM modes of operation. Its HEN (high enable) lead can force current to freewheel in the bottom two external power MOSFETs, maintaining the upper power MOSFETs off. Since it can switch at frequencies up to 1MHz, the HIP4080A is well suited for driving voice coil motors, switching power amplifiers and power supplies. HIP4080A can also drive medium voltage brush motors and two HIP4080As can be used to drive high performance stepper motors, since the short minimum "on-time" can provide fine micro-stepping capability. Short propagation delays of approximately 55ns maximize control loop crossover frequencies and dead-times which can be adjusted to near zero to minimize distortion, resulting in precise control of the driven load.
Drives N-channel FET full bridge including high side chop capability
Bootstrap supply maximum voltage to 95VDC
Drives 1000pF load at 1MHz in free air at 50°C with rise and fall times of typically 10ns
User-programmable dead time
Charge-pump and bootstrap maintain upper bias supplies
DIS (Disable) pin pulls gates low
Input logic thresholds compatible with 5 to 15V logic levels
Very low power consumption
Under-voltage protection
ESD sensitive device, take proper precaution while handling the device.
