HMC363S8G - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

HMC363S8G
Manufacturer

ADI
ChipWorker Part#

CW24296163
Category

RF Module, IC, Accessory
Package

SOIC-8
Description

Prescaler 5V 1/8 12000MHz 8Pin SOIC EP T/R
Documentation

Datasheet

HMC363S8G Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

HMC363S8G Specifications

Attribute	Attribute Value

Part Number	HMC363S8G
Manufacturer	ADI
ChipWorker Part#	CW24296163
Category	RF Module, IC, Accessory
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	8 Pin
Case/Package	SOIC-8
Frequency	0Hz ~ 12GHz
Supply Current	70 mA
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
	expand all
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
ECCN Code	3A001.a.11.b

Product Description

Product Details
The HMC363S8G(E) is a low noise Divide-by-8 Static Divider with InGaP GaAs HBT technology in an 8 lead surface mount plastic package. This device operates from DC (with a square wave input) to 12 GHz input frequency with a single +5V DC supply. The low additive SSB phase noise of -153 dBc/Hz at 100 kHz offset helps the user maintain good system noise performance.
**Applications**
Satellite Communication Systems
Fiber Optic
Point-to-Point
Point-to-Multi-Point Radios
VSAT
### Features and Benefits
Ultra Low SSB Phase Noise:
-153 dBc/Hz
Wide Bandwidth
Output Power: -6 dBm
Single DC Supply: +5V
S8G SMT Package
