HMC455LP3ETR ,Amplifier chip - ADI

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

122 points

Part No

HMC455LP3ETR
Manufacturer

ADI
ChipWorker Part#

CW1394778
Category

Amplifier chip
Package

QFN-16
Description

RF Amp Chip Single GP 2.5GHz 6V 16Pin QFN EP T/R
Documentation

Datasheet
Ships from

Moscow
Наличие

84279 pcs In Stock
Estimated Price

$ 0.19

Buy HMC455LP3ETR

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

HMC455LP3ETR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

HMC455LP3ETR Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	HMC455LP3ETR
Manufacturer	ADI
ChipWorker Part#	CW1394778
Category	Amplifier chip
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	16 Pin
Case/Package	QFN-16
Frequency	1.7GHz ~ 2.5GHz
Supply Current	150 mA
Number of Channels	1 Channel
Power Dissipation	1.04 W
Gain	13 dB
Test Frequency	1.9GHz ~ 2.2GHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	1040 mW
Supply Voltage	5 V
	expand all
Size-Height	0.95 mm
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Contains Lead

Similar & Replacement Parts

Similar products

Product Description

Product Details
The HMC455LP3(E) is a high output IP3 GaAs InGaP Heterojunction Bipolar Transistor (HBT) 1⁄2 watt MMIC amplifier operating between 1.7 and 2.5 GHz. Utilizing a minimum number of external components the amplifier provides 13 dB of gain and +28 dBm of saturated power at 56% PAE from a single +5 Vdc supply voltage. The high output IP3 of +42 dBm coupled with the low VSWR of 1.4:1 make the HMC455LP3(E) ideal driver amplifier for PCS/3G wireless infrastructures. A low cost, leadless 3x3 mm QFN surface mount package (LP3) houses the linear amplifier. The LP3 provides an exposed base for excellent RF and thermal performance.
Applications
Multi-Carrier Systems
GSM, GPRS & EDGE
CDMA & WCDMA
PHS
### Features and Benefits
Output IP3: +42 dBm
Gain: 13 dB
56% PAE @ +28 dBm Pout
+19 dBm W-CDMA Channel Power @ -45 dBc ACP
3x3 mm QFN SMT Package
