HMC536MS8G Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	HMC536MS8G
Manufacturer	ADI
ChipWorker Part#	CW62061907
Documentation	Datasheet
Number of Pins	8 Pin
Case/Package	TSSOP-8
Power Dissipation	867 mW
Test Frequency	6 GHz
Operating Temperature (Max)	85 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	867 mW
	expand all
Operating Temperature	-40℃ ~ 85℃
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	Non-Compliant
Lead-Free Status	Contains Lead
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

Product Details
The HMC536MS8G(E) is a DC to 6 GHz GaAs MMIC T/R switch in an 8 lead MSOP8G surface mount package with an exposed ground paddle. The switch is ideal for cellular/PCS/3G basestation applications featuring low 0.5 dB insertion loss and +55 dBm input IP3. Power handling is excellent up through 6 GHz with the switch offering a P0.1dB compression point of +29 dBm at +3 volts control. On-chip circuitry allows positive voltage control of 0/+3 volts or 0/+5 volts at very low DC currents.
Applications
Cellular/PCS/3G Infrastructure
ISM/MMDS/WiMAX
CATV/CMTS
Test Instrumentation
### Features and Benefits
Input P0.1dB: +34 dBm @ +5V
Insertion Loss: 0.5 dB
Positive Control: +3V or +5V
MS8G SMT Package, 14.8 mm²
Isolation: 27 dB
Very Fast Switching Speed
