IL300 ,Optocoupler, Optoisolator - VISHAY

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

145 points

Part No

IL300
Manufacturer

VISHAY
ChipWorker Part#

CW433783
Category

Optocoupler, Optoisolator
Package

DIP-8
Description

Optocoupler DC-IN 1CH Linear Photovoltaic DC-OUT 8Pin PDIP-8A
Documentation

Datasheet
Ships from

Moscow
Наличие

3335 pcs In Stock
Estimated Price

$ 1.9

Buy IL300

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

IL300 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

IL300 Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	IL300
Manufacturer	VISHAY
ChipWorker Part#	CW433783
Category	Optocoupler, Optoisolator
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	8 Pin
Case/Package	DIP-8
Voltage Rating (DC)	1.25 V
Output Voltage	500 mV
Number of Channels	1 Channel
Number of Positions	8 Position
Forward Voltage	1.25 V
Input Current	60 mA
Power Dissipation	0.21 W
Rise Time	1.75 µs
Bandwidth	200 kHz
Isolation Voltage	5300 Vrms
Gain	1.65 dB
Forward Current	60 mA
Output Voltage (Max)	500 mV
Input Current (Min)	60 mA
Reverse Breakdown Voltage	5 V
Maximum Forward Voltage (Max)	1.5 V
Forward Current (Max)	60 mA
Fall Time	1.75 µs
Operating Temperature (Max)	100 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	210 mW
	expand all
Operating Temperature	-55℃ ~ 100℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The IL300 is a Linear Optocoupler consists of an AlGaAs IRLED irradiating an isolated feedback and an output PIN photodiode in a bifurcated arrangement. The feedback photodiode captures a percentage of the LEDs flux and generates a control signal that can be used to servo the LED drive current. This technique compensates for the LEDs non-linear, time and temperature characteristics. The output PIN photodiode produces an output signal that is linearly related to the servo optical flux created by the LED. The time and temperature stability of the input-output coupler gain is insured by using matched PIN photodiodes that accurately track the output flux of the LED.
