IRF9530PBF ,MOSFET, MOSFET Transistor - Vishay Semiconductor

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

66 points

Part No

IRF9530PBF
Manufacturer

Vishay Semiconductor
ChipWorker Part#

CW79940263
Category

MOSFET, MOSFET Transistor
Package

TO-220
Description

MOSFET, Power; P-Ch; VDSS -100V; RDS(ON) 0.3Ω; ID -12A; TO-220AB; PD 88W; VGS +/-20V
Documentation

Datasheet
Ships from

Moscow
Наличие

60788 pcs In Stock
Estimated Price

$ 0.43

Buy IRF9530PBF

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

IRF9530PBF Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

IRF9530PBF Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	IRF9530PBF
Manufacturer	Vishay Semiconductor
ChipWorker Part#	CW79940263
Category	MOSFET, MOSFET Transistor
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220
Voltage Rating (DC)	-100 V
Current Rating	-12.0 A
Power Rating	88 W
Number of Positions	3 Position
Drain to Source Resistance (on) (Rds)	0.3 Ω
Polarity	P-Channel
Power Dissipation	88 W
Drain to Source Voltage (Vds)	100 V
Breakdown Voltage (Gate to Source)	±20.0 V
Continuous Drain Current (Ids)	-12.0 A
Rise Time	52.0 ns
Input Capacitance (Ciss)	860pF @25V(Vds)
Operating Temperature (Max)	175 ℃
Operating Temperature (Min)	-55 ℃
Power Dissipation (Max)	88000 mW
	expand all
Size-Length	10.41 mm
Size-Width	4.7 mm
Size-Height	9.01 mm
Operating Temperature	-55℃ ~ 175℃
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Similar & Replacement Parts

Similar products

IRF9530NSTRLPBF

International Rectifier

0.48 $/шт.

IRF9530NSTRRPBF

International Rectifier

Product Description

The IRF9530PBF is a -100V P-channel Power MOSFET, third generation HEXFET® power MOSFET provides the designer with the best combination of fast switching, ruggedized device design and low on-resistance. The package is universally preferred for all commercial-industrial applications at power dissipation levels to approximately 50W.
