The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

IRS2113MTRPBF
Manufacturer

Infineon
ChipWorker Part#

CW41888627
Category

FET Driver
RoHS

Lead free / RoHS Compliant
Description

MOSFET DRVR 600V 2.5A 2Out Hi/Lo Side Non-Inv 16Pin MLPQ EP T/R
Documentation

Datasheet

IRS2113MTRPBF Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

IRS2113MTRPBF Specifications

Attribute	Attribute Value

Part Number	IRS2113MTRPBF
Manufacturer	Infineon
ChipWorker Part#	CW41888627
Category	FET Driver
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	MLPQ-16
Rise/Fall Time	25ns, 17ns
Number of Outputs	2 Output
Output Current	2.5 A
Number of Positions	14 Position
Power Dissipation	2080 mW
Quiescent Current	180 µA
Rise Time	25 ns
Fall Time	17 ns
Fall Time (Max)	25 ns
Fall Time (Max)	35 ns
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	2080 mW
Supply Voltage	10V ~ 20V
Supply Voltage (Max)	20 V
Supply Voltage (Min)	10 V
	expand all
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Product Description

Summary of Features:
Floating gate driver designed for bootstrap operation
Fully operational to +600 V
Tolerant to negative transient voltage, dV/dt immune
Gate drive supply range from 10 V to 20 V
Undervoltage lockout for both channels
3.3 V logic compatible
Separate logic supply range from 3.3 V to 20 V
Logic and power ground +/- 5 V offset
CMOS Schmitt-triggered inputs with pull-down
Cycle by cycle edge-triggered shutdown logic
Matched propagation delay for both channels
Outputs in phase with inputs
