LT1085CT ,Voltage Regulator - Linear Technology

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

84 points

Part No

LT1085CT
Manufacturer

Linear Technology
ChipWorker Part#

CW90489600
Category

Voltage Regulator
Package

TO-220-3
Description

LDO Regulator Pos 1.25V to 28.5V 3A 3Pin(3+Tab) TO-220 LDO Regulator Pos 1.25V to 28.5V 3A 3Pin(3+Tab) TO-220
Documentation

Datasheet
Ships from

Moscow
Наличие

In Stock
Estimated Price

$ 9.11

Buy LT1085CT

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

LT1085CT Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

LT1085CT Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	LT1085CT
Manufacturer	Linear Technology
ChipWorker Part#	CW90489600
Category	Voltage Regulator
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220-3
Number of Outputs	1 Output
Output Voltage	1.25V ~ 28.5V
Output Current	3 A
Power Dissipation	30000 mW
Input Voltage (Max)	30 V
Input Voltage (Min)	2.55 V
Output Current (Max)	3 A
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	30000 mW
Input Voltage	2.55V ~ 30V
	expand all
Size-Height	9.4 mm
Product Lifecycle Status	Unknown
Packaging	Bulk
RoHS	Non-Compliant
Lead-Free Status	Contains Lead

Similar & Replacement Parts

Similar products

Product Description

DESCRIPTION
The LT® 1083 series of positive adjustable regulators are designed to provide 7.5A, 5A and 3A with higher efficiency than currently available devices. All internal circuitry is designed to operate down to 1V input-to-output differential and the dropout voltage is fully specified as a function
of load current. Dropout is guaranteed at a maximum of 1.5V at maximum output current, decreasing at lower load currents. On-chip trimming adjusts the reference voltage to 1%. Current limit is also trimmed, minimizing the stress on both the regulator and power source circuitry under overload conditions.
FEATURES
■ Three-Terminal Adjustable
■ Output Current of 3A, 5A or 7.5A
■ Operates Down to 1V Dropout
■ Guaranteed Dropout Voltage at Multiple Current Levels
■ Line Regulation: 0.015%
■ Load Regulation: 0.1%
■ 100% Thermal Limit Functional Test
■ Fixed Versions Available
■ Available in 3-Lead Plastic TO-220, TO-3P and DD Packages
