IRS2184PBF ,FET Driver - Infineon
The pictures are for reference only, and the specific specifications can be found in the product manual.
Popularity Score
83 points
-
Part NoIRS2184PBF
-
ManufacturerInfineon
-
ChipWorker Part#CW6819637
-
CategoryFET Driver
-
PackagePDIP-8
-
Description600V Half Bridge Driver IC with typical 1.9A source and 2.3A sink currents in 8 Lead PDIP package for IGBTs and MOSFETs. Also available in 8 Lead SOIC, 14 Lead SOIC, 14 Lead PDIP, and 14 Lead MLPQ 4x4.
-
DocumentationDatasheet
-
Ships fromMoscow
-
Наличие10 pcs In Stock
-
Estimated Price$ 4.32
