JDL36250 - Square D

The pictures are for reference only, and the specific specifications can be found in the product manual.

Part No

JDL36250
Manufacturer

Square D
ChipWorker Part#

CW289850810
Category

Circuit Breaker
Description

Circuit Breaker, Molded Case, 3Pole, 250A, 600VAC/250VDC, Unit Mount, Lug
Documentation

Datasheet

JDL36250 Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Arrow	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
Mouser	{{noList.partNo}} {{noList.mfr}}	0 {{ search_item }}	-	{{outStock}}
					{{submitRFQ}}

JDL36250 Specifications

Attribute	Attribute Value

Part Number	JDL36250
Manufacturer	Square D
ChipWorker Part#	CW289850810
Category	Circuit Breaker
Documentation	Datasheet
Mounting Style	DIN Rail
Current Rating	250 A
Voltage Rating	600VAC, 250VDC
	expand all
RoHS	RoHS Compliant
Lead-Free Status	Lead Free

Product Description

Well-suited to a wide range of applications, the PowerPact® H-, J- and L-Frame Molded Case Circuit Breakers provide a full complement of field installable accessories, field installable trip units and improved interrupting ratings. These molded case circuit breakers deliver unmatched design flexibility for 15 to 600 A applications and share identical mounting holes, handle locations, trim dimensions and accessories, allowing customers to standardize equipment designs.
**Features
* **H-Frame — 150 A Available in Both Standard and 100% Ratings with Standard Amperage Ratings from 15 to 150 A. Interrupting Ratings (AIR) Include D-18 kA, G-35 kA, J-65 kA and L-100 kA at 480 VAC
* J-Frame — 250 A Available in Both Standard and 100% Ratings with Standard Amperage Ratings from 150 to 250 A. Interrupting Ratings (AIR) Include D-18 kA, G-35 kA, J-65 kA and L-100 kA at 480 VAC
* L-Frame — 600 A Available in Both Standard and 100% Ratings with Standard Amperage Ratings from 250 to 600 A. Interrupting Ratings (AIR) Include D-18 kA, G-35 kA, J-65 kA and L-100 kA at 480 VAC
* Field Installable Accessories Are Common for H-, J- and L-Frame Circuit Breakers to Make Stocking and Installation Easy
* Unique Snap-In Terminals Make Converting Bus Bar and Lug Configurations Simple and Easy
* Field-Installable Trip Units Lower Inventory Costs and Reduce Stocking Space By Configuring Products at Point of Use
* Allows Design Standardization for 15 to 600 A Applications with Common Mounting Holes, Handle Locations, and Trim Dimensions for H-, J- and L-Frame
* Many Configuration Options Provide Application Flexibility, with I-Line®, Plug-In, Drawout, Rear Connected, Distribution Lug, Crimp Lug and Din-Rail Configurations
* Motor Operators, Rotary Handles and Cable Operators Provide Options for Integrating into a Variety of Applications
* Certified to Global Standards, Including UL, IEC, CSA and NOM. Also Marine Ratings
