L293DD013TR ,Motor Driver - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

256 points

Part No

L293DD013TR
Manufacturer

ST Microelectronics
ChipWorker Part#

CW474050
Category

Motor Driver
Package

SOIC-20
Description

**2xH-Br 1.2A 36V SO-20 SMD **
Documentation

Datasheet
Ships from

Moscow
Наличие

59137 pcs In Stock
Estimated Price

$ 1.19

Buy L293DD013TR

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

L293DD013TR Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

L293DD013TR Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	L293DD013TR
Manufacturer	ST Microelectronics
ChipWorker Part#	CW474050
Category	Motor Driver
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	20 Pin
Case/Package	SOIC-20
Supply Voltage (DC)	36.0V (max)
Number of Outputs	4 Output
Output Current	600 mA
Number of Channels	4 Channel
Number of Positions	20 Position
Power Dissipation	4000 mW
Switching Frequency	5 kHz
Operating Temperature (Max)	150 ℃
Operating Temperature (Min)	-40 ℃
Power Dissipation (Max)	4000 mW
Supply Voltage	4.5V ~ 36V
Supply Voltage (Max)	36 V
Supply Voltage (Min)	4.5 V
	expand all
Size-Length	13 mm
Size-Width	7.6 mm
Size-Height	2.65 mm
Operating Temperature	-40℃ ~ 150℃ (TJ)
Product Lifecycle Status	Active
Packaging	Tape & Reel (TR)
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

International Rectifier

0.36 $/шт.

Product Description

The Device is a monolithic integrated high voltage, high current four channel driver designed to accept standard DTL or TTL logic levels and drive inductive loads (such as relays solenoides, DC and stepping motors) and switching power transistors.
To simplify use as two bridges each pair of channels is equipped with an enable input. A separate supply input is provided for the logic, allowing operation at a lower voltage and internal clamp diodes are included.
This device is suitable for use in switching applications at frequencies up to 5 kHz.
The L293D is assembled in a 16 lead plastic packaage which has 4 center pins connected together and used for heatsinking
The L293DD is assembled in a 20 lead surface mount which has 8 center pins connected together and used for heatsinking.
**Key Features**
INTERNAL CLAMP DIODES
600mA OUTPUT CURRENT CAPABILITY PER CHANNEL
ENABLE FACILITY
1.2A PEAK OUTPUT CURRENT (non repetitive) PER CHANNEL
LOGICAL \"0\" INPUT VOLTAGE UP TO 1.5 V (HIGH NOISE IMMUNITY)
OVERTEMPERATURE PROTECTION

expand all
