LD1085V ,Voltage Regulator - ST Microelectronics

The pictures are for reference only, and the specific specifications can be found in the product manual.

Popularity Score

158 points

Part No

LD1085V
Manufacturer

ST Microelectronics
ChipWorker Part#

CW8925796
Category

Voltage Regulator
Package

TO-220-3
Description

STMICROELECTRONICS LD1085V LDO Voltage Regulator, Adjustable, 4.25V to 30V in, 1.3V drop, 1.25V to 4.25V/3A out, TO-220-3
Documentation

Datasheet
Ships from

Moscow
Наличие

288 pcs In Stock
Estimated Price

$ 0.79

Buy LD1085V

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

LD1085V Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

LD1085V Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	LD1085V
Manufacturer	ST Microelectronics
ChipWorker Part#	CW8925796
Category	Voltage Regulator
Documentation	Datasheet
Mounting Style	Through Hole
Number of Pins	3 Pin
Case/Package	TO-220-3
Supply Voltage (DC)	30.0V (max)
Number of Outputs	1 Output
Input Voltage (DC)	30.0V (max)
Output Voltage	1.25V ~ 28V
Output Current	3 A
Number of Positions	3 Position
voltage rating	1.3V @3A
Input Voltage (Max)	30 V
Input Voltage (Min)	4.25 V
Output Voltage (Max)	4.25 V
Output Voltage (Min)	1.25 V
Output Current (Max)	3 A
Operating Temperature (Max)	125 ℃
Operating Temperature (Min)	-40 ℃
Accuracy	±1 %
Supply Voltage (Min)	2.85 V
Input Voltage	≤30 V
	expand all
Size-Length	10.4 mm
Size-Width	4.6 mm
Size-Height	15.75 mm
Operating Temperature	-40℃ ~ 125℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
REACH SVHC Compliance	No SVHC
REACH SVHC Compliance Edition	2015/12/17
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The LD1085V is a low-drop Voltage Regulator able to provide up to 3A of output current. Dropout is guaranteed at a maximum of 1.2V at the maximum output current, decreasing at lower loads. The LD1085 is pin-to-pin compatible with the older 3-terminal adjustable regulator, but offers better performance in terms of drop and output tolerance. Unlike PNP regulator, where a part of the output current is wasted as quiescent current, the LD1085 quiescent current flows into the load and thus increase efficiency. Only a 10µF minimum capacitor is need for stability. On-chip trimming allows the regulator to reach a very tight output voltage tolerance, within ±1% at 25°C.
Internal power and thermal limit
Pin-out compatibility with standard adjustable VREG
