LM556CM/NOPB
Manufacturer

TI
ChipWorker Part#

CW12071436
Category

Clock Chip, Timing IC
Package

SOIC-14
Description

Timer, Oscillator & Pulse Generator IC, Dual, TTL, Astable, Monostable, 4.5V to 16V, SOIC-14
Documentation

Datasheet
Ships from

Moscow
Наличие

5 pcs In Stock
Estimated Price

$ 1.18

Buy LM556CM/NOPB

Stock is limited and changes quickly. Our 24/7 online sales team is ready to respond to your inquiries and orders at any time.

Real stock check

Best price from distributors

Engineer support

LM556CM/NOPB Global Supplier

{{ supplierTable.supplier }}	{{ supplierTable.part }}	{{ supplierTable.availability }}	MOQ	{{ supplierTable.delivery_date }}

{{viewMore}}
{{viewMore}}
DigiKey	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Arrow	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
Mouser	{{noList.partNo}} {{noList.mfr}}	{{ low_stock_text }}	1	{{weeks_text}}
					{{submitRFQ}}
Chipworker	{{noList.partNo}} {{noList.mfr}}	{{stockAvailability}} {{ search_item }}	{{moq}}	1	6 - 8 {{delivery_date}}

Update Data

Chipworker Certification

ChipWorker Qualifications — ISO 9001, ISO 45001, ISO 14001, MA Certification. Over 11 years of experience, more than 1000 clients in Russia, support for small MOQ

11+ years sourcing experience

1000+ russia customers

ISO certified supplier

Support small MOQ

*Photos of Our Actual 800 m² Warehouse

LM556CM/NOPB Specifications

Consulting Engineer >>

Attribute	Attribute Value

Part Number	LM556CM/NOPB
Manufacturer	TI
ChipWorker Part#	CW12071436
Category	Clock Chip, Timing IC
Documentation	Datasheet
Mounting Style	Surface Mount
Number of Pins	14 Pin
Case/Package	SOIC-14
Frequency	100 kHz
Supply Voltage (DC)	16.0V (max)
Power Rating	410 mW
Input Voltage (DC)	15.0V (max)
Output Current	≤100 mA
Supply Current	10 mA
Number of Positions	14 Position
Power Dissipation	410 mW
Quiescent Current	3.00 mA
Operating Temperature (Max)	70 ℃
Operating Temperature (Min)	0 ℃
Power Dissipation (Max)	410 mW
Supply Voltage	4.5V ~ 16V
Supply Voltage (Max)	16 V
Supply Voltage (Min)	4.5 V
	expand all
Size-Length	8.64 mm
Size-Width	3.91 mm
Size-Height	1.45 mm
Operating Temperature	0℃ ~ 70℃
Product Lifecycle Status	Active
Packaging	Tube
RoHS	RoHS Compliant
Lead-Free Status	Lead Free
ECCN Code	EAR99

Similar & Replacement Parts

Similar products

Product Description

The LM556 dual-timing circuit is a highly-stable controller capable of producing accurate time delays or oscillation. The LM556 device is a dual-timing version of the LM555 device. Timing is provided by an external resistor and capacitor for each timing function. The two timers operate independently of each other, sharing only VCC and ground. The circuits may be triggered and reset on falling waveforms. The output structures may sink or source 200 mA.
